YESWELDER
125 Amp Mini Stick Welder 110V Portable ARC MMA Welding Machine Lift TIG Capable with Large LED Display Adjustable Hot Start and Arc Force for DIY
125 Amp Mini Stick Welder 110V Portable ARC MMA Welding Machine Lift TIG Capable with Large LED Display Adjustable Hot Start and Arc Force for DIY
Couldn't load pickup availability
Ultra-Lightweight and Portable: Weighing only 4.4 lbs (2kg) with compact dimensions, this mini inverter welder features a built-in handle, making it ideal for high-altitude operations, tight spaces, and on-the-go storage.
Intelligent LED Display: Equipped with a large, clear digital screen that displays current, function modes, and electrode dimensions, enabling precise knob adjustments without removing welding gloves.
Versatile Welding Capability: Delivers 20-125 Amps output on 110V power. Compatible with electrodes up to 1/8 inch, including E6010, E6011, E6013, and E7018, for welding mild steel and stainless steel.
Smart Arc Control: Features adjustable Hot Start for quick, reliable arc ignition and auto-adaptive Arc Force to prevent electrode sticking, ensuring smooth weld pools and reduced spatter.
Safety and Protection: Built with automatic compensation for voltage fluctuation and comprehensive safeguards against over-current, overload, and overheating to ensure safe operation and equipment longevity.
Q: Can I plug this into a regular household outlet?
Q: Can I plug this into a regular household outlet?
A: Yes, this machine runs on standard 110V/120V power.
Important Note: Stick welding draws a lot of power. For best performance, we recommend using a 20-Amp dedicated circuit breaker. If you are using a standard 15-Amp outlet, avoid running the machine at full max power (125A) to prevent tripping the breaker.
Q: Do I need to buy a plug adapter?
Q: Do I need to buy a plug adapter?
A: No. Since this is a dedicated 110V machine, it comes pre-wired with a standard US household plug. You can start welding right out of the box.
Q: Can I use an extension cord?
Q: Can I use an extension cord?
A: Because the included cables are 6.5ft long, you may need an extension cord. You must use a heavy-duty 12-gauge or 10-gauge extension cord (industrial grade). Using a thin household cord will cause a voltage drop and make the machine perform poorly.
Q: How thick of metal can I weld with 125 Amps?
Q: How thick of metal can I weld with 125 Amps?
A: This machine is perfect for DIY repairs!
Ideal Thickness: 1/16" up to 1/8" (3mm) steel.
Max Thickness: You can weld up to 3/16" steel using multiple passes and beveling the edges.
Recommended Rods: We suggest using 3/32" or 1/16" diameter electrodes for the best experience on this machine.
Q: Will it run 6010 or 6011 rods?
Q: Will it run 6010 or 6011 rods?
A: Yes! Despite its small size, the ARC-125DS-PRO is engineered to run E6010 and E6011 cellulose rods, which are great for welding through rust, paint, and dirt on outdoor repairs. It also runs E7018 and E6013 smoothly.
Q: Can I TIG weld with this?
Q: Can I TIG weld with this?
A: Yes, the machine has a Lift TIG mode.
Requirement: The TIG torch is not included. You will need to purchase a WP-17V torch (with a 10-25 DINSE connector) and Argon gas separately to use this feature.
Note: It cannot weld Aluminum (DC output only).
Features & Controls
Q: What is "Hot Start" and "Arc Force"?
Q: What is "Hot Start" and "Arc Force"?
A: These features help beginners weld like pros:
Hot Start: Automatically boosts the current when you strike the rod, making it easy to start the arc without sticking.
Arc Force: Monitors the weld and increases power if the rod gets too close to the metal, preventing it from freezing in the puddle. Both are adjustable on the digital screen!
Q: How portable is this welder?
Q: How portable is this welder?
A: It is Ultra-Portable! The unit weighs only 4.4 lbs (2kg) and measures just 9.3 inches long. It fits easily on a shelf, in a backpack, or in a toolbox, making it the perfect "grab-and-go" welder for maintenance jobs.
Q: What does the LED display show?
Q: What does the LED display show?
A: The intelligent display shows:
Current Amperage (20-125A).
Function Mode (Stick vs. Lift TIG).
Electrode Size Recommendation: It gives you a visual guide on which rod size matches your amperage setting.
